Product certifications
CE
CULus
CSA
UL 61010-2-201
RCM
UKCA
DNV (DC model without HDD/fan/ EtherCAT card/22" wide display with expansion slot)
ATEX zone 22 dust
ATEX zone 2
CULus Class 1 Division 2 (without DIO option)
IECEx zone 2 (DC model, front USB cover must be locked with screw)
IECEx zone 22 (DC model, front USB cover must be locked with screw)
NEMA degree of protection
NEMA 4X/13
Ambient air temperature for operation
0…55 °C wall mounting (without HDD) side conforming to IEC 60068-2-2
0…55 °C book mounting (without HDD) side
0…50 °C flat mounting (without HDD) top
0…50 °C book mounting (without HDD) top
0…40 °C wall mounting (with HDD) side
0…40 °C book mounting (with HDD) side
0…40 °C flat mounting (with HDD) top
0…40 °C book mounting (with HDD) top
0…55 °C panel (without HDD) landscape
0…50 °C panel (without HDD) portrait
0…40 °C panel (with HDD) landscape
0…40 °C panel (with HDD) portrait
Shock resistance
147 m/s² X, Y, Z directions for 3 times conforming to IEC 61131-2
