Product certifications
RCM
KC
UKCA
DNV (except 22" wide display)
EAC
ATEX zone 2
ATEX zone 22 dust
IECEx zone 2 (DC model, front USB cover must be locked with screw)
CULus Class 1 Division 2
IECEx zone 22 (DC model, front USB cover must be locked with screw)
Standards
CE
FCC part 15
UL 61010-2-201
CSA C22.2 No 61010-2-201
Ambient air temperature for operation
0…50 °C
Ambient air temperature for storage
-20…60 °C
Storage Relative Humidity
10…90 % without condensation
Vibration resistance
1 gn (f = 5…9 Hz) single amplitude conforming to IEC 61131-2
1 gn (f = 9…150 Hz) fixed amplitude conforming to IEC 61131-2
1 gn X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2
Shock resistance
147 m/s² conforming to IEC 61131-2
147 m/s² 3 shocks in each direction X, Y and Z
Electromagnetic compatibility
Electrostatic discharge immunity test - test level: 6 kV (contact discharge) conforming to IEC 61000-4-2 level 3
Electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 61000-4-2 level 3
Electrical fast transient/burst immunity test - test level: 2 kV (power ports) conforming to IEC 61000-4-4
Electrical fast transient/burst immunity test - test level: 1 kV (signal ports) conforming to IEC 61000-4-4
