Serial Interface
* For host controllers and connection cables, refer to the corresponding device driver manual of your screen editing software.
| Product Name | Model No. | Supported Product | Description |
|---|---|---|---|
| 9-pin-to-25-pin RS-232C Conversion Cable (0.2 m) | CA3-CBLCBT232-01 | Standard Box / Power Box / Open Box | Cable for converting a D-Sub 9-pin plug to a D-Sub 25-pin socket (RS-232C). |
| RS-422 9/25-pin Conversion Cable (0.2 m) | PFXZCBCBCVR41 | Standard Box / Power Box / Open Box | Cable for converting a D-Sub 9-pin plug to a D-Sub 25-pin socket (RS-422). |
| COM Port Conversion Adapter | CA3-ADPCOM-01 | Standard Box / Power Box / Open Box | Connects optional RS-422 communication items to Serial Interface. |
| RS-422 Terminal Block Conversion Adapter | PFXZCBADTM1 | Standard Box / Power Box / Open Box | Connects output from a Serial Interface (D-sub 9 pin plug) directly to an RS-422 terminal block. |
| RS-232C Isolation Unit | CA3-ISO232-01 | Standard Box / Power Box / Open Box | Connects a host controller to this product and provides isolation. (RS-232C and RS-422 are switchable). |
USB (Type A)
| Product Name | Model No. | Supported Product | Description |
|---|---|---|---|
| USB Cable (5 m) | FP-US00 | Standard Box / Power Box / Open Box | Connects a USB printer (TYPE-B). |
| USB Front Cable (1 m) | CA5-USBEXT-01 | Standard Box / Power Box / Open Box | Extension cable attaching USB interface to front panel. |
| USB-Serial (RS-232C) Conversion Cable (0.5 m) | CA6-USB232-01 | Standard Box / Power Box | Cable for converting a USB interface into a serial interface (RS-232C). Allows connection to modems*2or bar code readers *3 that support RS-232C. |
| USB/RS-422/485 Conversion Adapter | PFXZCBCBCVUSR41 | Standard Box / Power Box | Adapter for connecting this product (USB Type A) to an external device (RS-422/RS-485). |
| EZ Tower Light tube mounting with fixing plate | PFXZCETWHA1 | Standard Box / Power Box *3 | USB Connection Type Monolithic EZ Tower Light tube mounting with fixing plate. |
| EZ Tower Light with base mounting | PFXZCETWW1 | Standard Box / Power Box *3 | USB Connection Type Monolithic EZ Tower with base mounting. |
| EZ Illuminated Switch | PFXZCCEUSG1 | Standard Box / Power Box *3 | A unit of 5 illuminated switches with multiple color LED connected to this product via USB. |
| EZ Fingerprint Recognition Unit | PFXZCCEUSS1 | Standard Box / Power Box *3 | Fingerprint recognition unit connected to this product via USB. |
| EZ Numpad | PFXZCCEUKB1 | Standard Box / Power Box *3 / Premium Display | Numpad connected to this product via USB. |
USB (mini B)
| Product Name | Model No. | Supported Product | Description |
|---|---|---|---|
| USB Transfer Cable (USB Type A / mini-B) (1.8 m)*1 | ZC9USCBMB1 | Standard Box / Power Box / Open Box / Premium Display | Cable for transferring screen data from a PC (USB Type A) to this product (USB mini-B). |
| USB Panelmount Extension Cable (USB mini-B) (1 m) | ZC9USEXMB1 | Standard Box / Power Box / Open Box | Extension cable that attaches to the USB (mini-B) interface on the front side of the operation panel. |
| USB Clamp mini-B (1 port) | ZC9USCLMB1 | Standard Box / Power Box / Open Box | Clamp to prevent disconnection of USB cable (USB/mini-B, 1 port, 5 clamps/set). |
Software
| Product Name | Model No. | Description |
|---|---|---|
| GP-Pro EX Software Licenses and Related Software | See Product webpage for the details. | HMI Screen editor & Logic Programming Software and Related Software |
| Pro-face Connect | See Product webpage for the details. | "Pro-face Connect" is a ready-to-use solution for Secure Remote Access Over the Internet |
Other
| Product Name | Model No. | Supported Product | Description | |
|---|---|---|---|---|
| DVI-D Output Interface | DVI-D Cable | FP-DV01-50 | Open Box | DVI-D cable used to send the image signal from this product to Pro-face's flat panel displays and other commercial-type displays. DVI 1.0 compliant (DVI-D 24-pin plug) (5 m). |
| Auxiliary Output / Speaker Output Interface | AUX Connector | PFXZCDCNAUX1 | Power Box / Open Box | AUX connector required in case an external output is used (5 pcs/set). |
| Storage*4 | SD Memory Card (4GB) | PFXZCBSD4GC41 | Standard Box / Power Box / Open Box | SD Memory Card (4GB, MLC, CLASS4) |
| CFast (32GB) | PFXZCDSCCFA321 | Open Box | CFast Card (32GB, SLC) for CFast Card Slot (Storage) | |
| Screen Protection Sheet | 10-inch | PFXZCBDS101 | 10-inch Premium Display | Disposable, dirt-resistant sheet for the display (5 sheets/set) |
| 12-inch | CA7-DFS12-01 | 12-inch Premium Display / Advanced Display | ||
| 15-inch | CA3-DFS15-01 | 15-inch Premium Display | ||
| 7-inch Wide | PFXZCBDS72 | 7-inch Wide Advanced Display | ||
| 10-inch Wide | PFXZCDDS102 | 10-inch Wide Advanced Display | ||
| 12-inch Wide | PFXZCDDS122 | 12-inch Wide Advanced Display | ||
| UV Protection Sheet | 10-inch | PFXZCFUV101 | 10-inch Premium Display | Ultraviolet protection for the display (1 piece) |
| 12-inch | PFXZCFUV121 | 12-inch Premium Display / Advanced Display | ||
| 15-inch | PFXZCFUV151 | 15-inch Premium Display | ||
| 7-inch Wide | PFXZCFUV72 | 7-inch Wide Advanced Display | ||
| 10-inch Wide | PFXZCFUV102 | 10-inch Wide Advanced Display | ||
| 12-inch Wide | PFXZCFUV122 | 12-inch Wide Advanced Display | ||
| Environment Cover | 10-inch | PFXZCDOP101 | 10-inch Premium Display | Environmental resistant cover for the display (1 piece) For details of the oil and chemical resistant perfomance, please refer to the Installation Guide. |
| 12-inch | PFXZCDOP121 | 12-inch Premium Display / Advanced Display | ||
| 15-inch | PFXZCDOP151 | 15-inch Premium Display | ||
| Anti-Glare Sheet | 18.5-inch Wide | PFXZCHAG192 | 19-inch Wide Premium Display | Prevent reflections, dirt-resistant sheet for the SP unit's screen (5 sheets/set) |
| 15.6-inch Wide | PFXZCHAG152 | 15-inch Wide Premium Display | ||
| Panel Cutout Adapter | 10-inch | CA4-ATM10-01 | 10-inch Premium Display | Panel cutout adapter for mounting 10-inch Premium Display in cutout for GP-2500/2600 series, AGP-3500L/ AGP-3500S/ AGP-36*0T/ AGP-36*0U. |
| 7-inch Wide | PFXZCDAT72 | 7-inch Wide Advanced Display | Panel cutout adapter for mounting 7-inch Wide Advanced Display in cutout for GP-2400, GP-3400, and GP-4400 Series. | |
| Enhanced Front USB Cover (With Screw) | PFXZCDCVUS1 | Premium Display | Front USB cover with fixing screw, corresponding to IP66F, IP67F, Type 1/4X Indoor use only /13 or ATEX certifications (5 pieces/set) | |
| Replacement Battery *5 | PFXZCBBT1 | Standard Box / Power Box / Open Box | Primary battery for time data backup (1 piece) | |
| DC Power Supply Connector with fixable screws (Straight type) | CA7-ACCNL-01 | Premium Display / Advanced Display *6 | Connector with fixable screws to connect DC power supply cables (Straight type, 5 pieces/set) | |
Maintenance
| Product Name | Model No. | Supported Product | Description |
|---|---|---|---|
| 10-inch Installation Gasket | PFXZCDWG101 | 10-inch Premium Display | Provides dust and moisture resistance when this product is installed into a solid panel (1 piece) |
| 12-inch Installation Gasket | PFXZCDWG121 | 12-inch Premium Display / Advanced Display | |
| 15-inch Installation Gasket | PFXZCDWG151 | 15-inch Premium Display | |
| 7-inch Wide Installation Gasket | PFXZCDWG72 | 7-inch Wide Advanced Display | |
| 10-inch Wide Installation Gasket | PFXZCDWG102 | 10-inch Wide Advanced Display | |
| 12-inch Wide Installation Gasket | PFXZCDWG122 | 12-inch Wide Advanced Display | |
| 15-inch Wide Installation Gasket | PFXZCGWG152 | 15-inch Wide Premium Display | |
| 19-inch Wide Installation Gasket | PFXZCGWG192 | 19-inch Wide Premium Display | |
| USB Clamp TypeA (1 port) | PFXZCBCLUSA1 | Standard Box / Power Box / Open Box / Advanced Display | Clamp to prevent disconnection of USB cable (USB/A, 1 port, 5 clamps/set) |
| DC Power Supply Connector (Straight type) | PFXZCBCNDC1 | Premium Display / Advanced Display | Connector to connect DC power supply cables (Straight type, 5pcs/set) |
| DC Power Supply Connector (Angle type) | PFXZCBCNDC2 | Premium Display / Advanced Display (except 7-inch Wide Advanced Display) | Right-angle connector to connect DC power supply cables (5 pcs/set) |
| CFast (32 GB) | PFXZCDSCCFA322 | Open Box (SP-5B41) | CFast Card (32 GB, MLC) for System Card |
| CFast (16 GB) | PFXZCDSCCFA162 | Open Box (SP-5B40) | CFast Card (16 GB, MLC) for System Card |
| SD Memory Card (1 GB) | PFXZCDSD1GC61 | Power Box | SD Memory Card (1 GB, SLC, Class 6) for System Card |
Expansion Unit
| Product Name | Model No. | Description | Supported Module | Others |
|---|---|---|---|---|
| Multi Display Adapter | PFXZCDADEXR1 | Adapter that attaches to the rear of the displays when the SP5000 Series Box and displays are separately located. (one is required for each display if connecting multiple displays to a single box.) | Premium Display Advanced Display | Manual |
| VESA Mount Adapter | PFXZSPADVS1 | Adapter to mount SP5000 Series Display Module on a VESA arm. (Multi Display Adaptor is required in addition.) | Multi Display Adapter | - |
| DIO Connector for Multi Display Adapter * Maintenance Item | PFXZCFCNIO1 | Connector for DIO interface (5 pieces/set) | Multi Display Adapter | - |
| PROFIBUS DP Slave/MPI Unit *7 | PFXZCDEUPF1 | Expansion unit that enables participation of the SP5000 Series, in the PROFIBUS network and communication with the PROFIBUS DP master. | Power Box | Manual |
| J1939 Unit | PFXZCHEUJ1 | Expansion unit that enables participation in the J1939 communication network. | Box Module | Manual |
CANopen
TM3 CANopen Connection
CANopen unit
| Model No. | Description | Details | Guide Book | IO Configurator |
|---|---|---|---|---|
| TM3BCCO *8 | TM3 Bus Coupler CANopen | Product page |
Modicon TM3 guidebook *Before using TM3, be sure to read this TM3 Guide book with recommended substitutes and precautions for replacing the EX module. |
*TM3BC IO Configurator software is required to configure TM3BCCO and TM3. |
Modicon TM3 Module
| Model No. | Description | Details | Guide Book | IO Configurator |
|---|---|---|---|---|
| TM3DI8 | 8-ch Sink/Source Inputs (Screw) | Product page |
Modicon TM3 guidebook *Before using TM3, be sure to read this TM3 Guide book with recommended substitutes and precautions for replacing the EX module. |
*TM3BC IO Configurator software is required to configure TM3BCCO and TM3. |
| TM3DI8G | 8-ch Sink/Source Inputs (Spring) | Product page | ||
| TM3DI16 | 16-ch Sink/Source Inputs (Screw) | Product page | ||
| TM3DI16G | 16-ch Sink/Source Inputs (Spring) | Product page | ||
| TM3DQ8T | 8-ch Transistor Source Outputs (Screw) | Product page | ||
| TM3DQ8TG | 8-ch Transistor Source Outputs (Spring) | Product page | ||
| TM3DQ8U | 8-ch Transistor Sink Outputs (Screw) | Product page | ||
| TM3DQ8UG | 8-ch Transistor Sink Outputs (Spring) | Product page | ||
| TM3DQ8R | 8-ch Relay Outputs (Screw) | Product page | ||
| TM3DQ8RG | 8-ch Relay Outputs (Spring) | Product page | ||
| TM3DQ16TK | 16-ch Transistor Source Outputs (HE10) | Product page | ||
| TM3DQ16UK | 16-ch Transistor Sink Outputs (HE10) | Product page | ||
| TM3DQ16R | 16-ch Relay Outputs (Screw) | Product page | ||
| TM3DQ16RG | 16-ch Relay Outputs (Spring) | Product page | ||
| TM3DM8R | 4-ch Sink/Source Inputs, 4-ch Relay Outputs (Screw) | Product page | ||
| TM3DM8RG | 4-ch Sink/Source Inputs, 4-ch Relay Outputs (Spring) | Product page | ||
| TM3DM24R | 16-ch Sink/Source Inputs, 8-ch Relay Outputs (Screw) | Product page | ||
| TM3DM24RG | 16-ch Sink/Source Inputs, 8-ch Relay Outputs (Spring) | Product page | ||
| TM3AI2H | 2-ch Voltage/Current Inputs (Screw) | Product page | ||
| TM3AI2HG | 2-ch Voltage/Current Inputs (Spring) | Product page | ||
| TM3AQ2 | 2-ch Voltage/Current Outputs (Screw) | Product page | ||
| TM3AQ2G | 2-ch Voltage/Current Outputs (Spring) | Product page | ||
| TM3TI4 | 4-ch Voltage/Current or Temperature Inputs (Screw) | Product page | ||
| TM3TI4G | 4-ch Voltage/Current or Temperature Inputs (Spring) | Product page | ||
| TM3AM6 | 4-ch Voltage/Current Inputs, 2-ch Voltage/Current Outputs (Screw) | Product page | ||
| TM3AM6G | 4-ch Voltage/Current Inputs, 2-ch Voltage/Current Outputs (Spring) | Product page | ||
| TM3TM3 | 2-ch Temperature or Voltage/Current Inputs, 1-ch Voltage/Current Output (Screw) | Product page | ||
| TM3TM3G | 2-ch Temperature or Voltage/Current Inputs, 1-ch Voltage/Current Output (Spring) | Product page |
HTB CANopen Connection
| Product Name | Model No. | Description | Supported Module | Others |
|---|---|---|---|---|
| CANopen Master Unit *9 | PFXZCHEUCAM1 | Expansion master unit to connect CANopen slave unit (bit input/output 1024 points / integer input/output 256 points) | Power Box | - |
| CANopen Slave HTB Unit | HTB1C0DM9LP | Slave unit supporting CANopen with 12 digital inputs, 6 relay outputs and 2 transistor source outputs. Up to 7 units of EX modules can be connected. | CANopen Master Unit | Manual |
| DIO Connector for HTB * Maintenance Item | CA7-HTBCNSET-01 | DIO Connector for HTB (13-pin connector for input and 16-pin connector for output, 1 pc each/set) | ||
| 8-point Input Module | EXM-DDI8DT | 8-point sink-source shared type expansion unit | Manual | |
| 16-point Input Module | EXM-DDI16DT | 16-point sink-source shared type expansion unit | ||
| 8-point relay output module | EXM-DRA8RT | 8-point relay output (2 common) type expansion unit | ||
| 16-point relay output module | EXM-DRA16RT | 16-point relay output (2 common) type expansion unit | ||
| 8-point transistor output module | EXM-DDO8UT | 8-point transistor output sink type expansion unit | ||
| 16-point transistor output module | EXM-DDO16UK | 16-point transistor output sink type expansion unit | ||
| 8-point transistor output module | EXM-DDO8TT | 8-point transistor output source type expansion unit | ||
| 16-point transistor output module | EXM-DDO16TK | 16-point transistor output source type expansion unit | ||
| 4-Point Input/ 4-Point Output Module | EXM-DMM8DRT | 4-point input sink-source and 4-point relay output type expansion unit (1 common) mixed I/O unit | ||
| 16-Point Inputs/ 8-point Relay Output Module | EXM-DMM24DRF | 16-point input sink-source / 8-point relay output mixed I/O type expansion unit | ||
| 2-ch Analog Input Module | EXM-AMI2HT | 2-ch analog input type expansion unit | ||
| 2-ch Thermocouple Pt100 Input/ 1-ch Analog Output Module | EXM-ALM3LT | 2-ch analog input / 1-ch analog output type expansion unit | ||
| 2-ch Analog Input/ 1-ch Analog Output Module | EXM-AMM3HT | 2-ch analog input / 1-ch analog output type expansion unit | ||
| 1-ch Analog Output Module | EXM-AMO1HT | 1-ch analog output type expansion unit | ||
| 4-ch Voltage, Current, Pt100/ Pt1000/ Ni100/ Ni1000 Input Module | EXM-AMI4LT | 4-ch Voltage, Current, Temperature Expansion Unit | ||
| 2-ch Analog Output Module | EXM-AVO2HT | 2-ch analog output type expansion unit | ||
| 4-ch Analog Input/ 2-ch Analog Output Module | EXM-AMM6HT | 4-ch analog input / 2-ch analog output expansion unit | ||
| 8-ch Temperature Pt100/ Pt1000 Input Module | EXM-ARI8LT | 8-ch temperature input type expansion unit | ||
| MIL Connector (20 pin) for EX module * Maintenance Item | CA6-EXMCNHE20P-01 | Connector for EX Module (5 pcs/set) | ||
| MIL Connector (11 pin) for EX module * Maintenance Item | CA6-EXMCNHE11P-01 | |||
| MIL Connector (10 pin) for EX module * Maintenance Item | CA6-EXMCNHE10P-01 |
FLEX NETWORK
| Product Name | Model No. | Description | Supported Module | Others |
|---|---|---|---|---|
| FLEX NETWORK Master Unit *10 | PFXZCHEUFN1 | FLEX NETWORK Master Unit for SP5000 Series | Power Box | - |
| 32-point input Sink/Source and 32-point transistor output Sink type | FN-XY32SKS41 | Input/output combination I/O unit of 32-point input sink/source and 32-point transistor output Sink type | FLEX NETWORK Master Unit | |
| 32-point input Sink / Source type | FN-X32TS41 | I/O unit of 32-point input sink/source sharing type | ||
| 16-point input Sink/Source and 16-point transistor output Sink type | FN-XY16SK41 | Input/output combination I/O unit of 16-point input sink/source and 16-point transistor output Sink type | ||
| 16-point input Sink/Source and 16-point transistor output Source type | FN-XY16SC41 | Input/output combination I/O unit of 16-point input sink/source and 16-point transistor output Source type | ||
| 2-channel Analog/Digital Conversion Unit | FN-AD02AH41 | Converts 2-channel analog signals to digital signals | ||
| 2-channel Digital/Analog Conversion Unit | FN-DA02AH41 | Converts 2-channel 12-bit digital signals to analog signals and outputs the result | ||
| Communication Cable (50m) | FN-CABLE2050-31-MS | Cables for connecting FLEX NETWORK master unit and FLEX NETWORK units | ||
| Communication Cable（200m） | FN-CABLE2200-31-MS | |||
| FLEX NETWORK Connector * Maintenance Item | PFXZCHCNFN2 | Connector to attach FLEX NETWORK master unit (5 pcs/set) | ||
| 64-point DIO Connector * Maintenance Item | GLC-DIOCN03 | FN-XY32SK41 Connectors (2 pcs/set) |
Multi-Converter (Multi-Data Box)
| Product Name | Model No. | Description | Others |
|---|---|---|---|
| DC Power Supply Adapter | PFXZCDADEXP1 | Adapter that attaches to the SP5000 Series Box Module to supply power to the Box Module. | Manual |
| Wall Mount Adapter | PFXZSPADWM1 | Adapter to mount SP5000 Series Box Module on a wall of control cabinet. |
*1 You can connect using just one of the available USB interfaces.
*2 For supported models, refer to Pro-face’s support site "Otasuke Pro!"(https://www.proface.com/otasuke/).
*3 Make sure your screen editing software supports the product.
*4 You can also use a commercial type.
*5 SP5000 Series can save NVRAM (Backup memory) and RTC (Time) without battery. But when you need to keep RTC (Time) more than 100 days without turning on electricity,you need to add the option.
*6 Except 7-inch Wide Advanced Display
*7 MPI (12MB) Communication is not supported.
*8 EX Module cannot connect to TM3 Bus Coupler CANopen unit.
*9 TM3 module cannot connect to CANopen Slave HTB Unit.
*10 Also R7 Series of M-System Co., Ltd. (FLEX NETWORK remote I/O) can be connected.
